FZP32
FZP32
Dynamic and you
The FZP32 is our next generation FZP-line 5-axis gantry for the machining of aluminum, fiber composite materials,
plastics and resin. The particularly rigid and newly developed center lead portal enables us to meet the ever growing demands in the aerospace and model/mold making industry. Its thermo-symmetrical construction makes the FZP32 less susceptible to adverse ambient conditions thus ensuring excellent surface quality.
The flexible design of our FZP-line gantries offer different lengths and height versions, as well as extensive equipment options, such as process cooling with minimum quantity lubrication and/or an effective
dust extraction system for abbrasive materials and resin. Due to it’s great flexibility in material handling, high surface quality and accuracy, the FZP32 offers true superior machining with high efficiency.
Technical Data
Working ranges
| X-Axis | 3 000 – 10 000 mm (118"-394") |
| Y-Axis | 2 500 – 4 000 mm (98"-157") |
| Z-Axis | 1 250 – 2 500 mm (49"-98") |
Table (optional)
| Length | 3 000 – 10 000 mm (118"-394") |
| Width | 2 500 – 4 000 mm (98"-157") |
| Table load | 10 000 kg/m² |
| T-Slots (longitudinal) | 18<sup>H12 |
| Pitch of T-slots | 250 mm (9") |
| Table surface | even/above floor level |
Drives – Linear Axes
| Feed rate X-, Y-, Z-axis | up to 60 m/min (2362 ipm) |
| Acceleration X-, Y-, Z-axis | up to 3 m/s² (118 in/s²) |
Dimensions
| Required space (without peripherals) | Length | 5 300 – 12 500 mm (209"-492") |
| Width | 6 300 – 8 000 mm (248"-315") | |
| Height | 3 700 – 7 200 mm (146"-283") |
Accuracy
| Standard accuracy | in accordance to VDI/DGQ 3441 or ISO 230-2 |
| Special accuracy | on request |
CNC control (select from)
| Heidenhain TNC7 | Siemens SINUMERIK ONE |
